Locator Two is a fully autonomous, highly accurate, 3D Monitoring Solution designed for object monitoring.
| PRODUCT INFO | Locator Two |
|---|---|
| PRODUCT WEIGHT | 1650 g (excluding box) |
| PRODUCT DIMENSIONS | 280 x 155 x 79 mm 285 x 170 x 85 mm (box dimensions) |
| OPERATING CONDITIONS | –40°C to +60 |
| # | TOPIC | FEATURE | TECHNICAL DETAILS |
|---|---|---|---|
| 1 | Sensors | GNSS, tilt meter, temperature and barometer | |
| 2 | Connectivity | LTE-M (bands: B1, B2, B3, B4, B5, B8, B12, B13, B14, B18, B19, B20, B25, B26, B28, B66) | |
| 3 | Power | Supercapacitor | 4.2 V (air transport safe) |
| Solar panel | 2 x 1W | ||
| Charging | Solar panel or USB (with custom cable) | ||
| 4 | Temperature | Inside temperature | Each measurement from –40°C to +60°C |
| 5 | Resolution | Temperature resolution | 0.1° C |
| Barometer resolution | 0.1 hPa | ||
| 6 | Casing / material | Outside | ASA / RAL 7047 |
| Bracket | Stainless Steel A4 | ||
| 7 | Mounting | Options | Screws, gluing |
| 8 | GNSS | Constellations & bands | GPS, GLONASS, Galileo, BeiDou and QZSS L1C/A, L1OF, L2C, L2OF, B1I, B2I, E1B/C and E5b multi band, (184 channels) |
| Precision | Post Processed Static (PPS): – Horizontal Precision: 2 mm + 0.5 ppm (1σ) – Vertical Precision: 4 mm + 0.5 ppm (1σ) – Long term trend-monitoring precision: <1 mm* | ||
| Measurement frequency | 1 to 96 times per day (configurable via the Parvamoti platform) | ||
| 9 | Tilt meter | Sensor | 3-axis MEMS accelerometer |
| Range | +10° (due to reliable GNSS measurement) | ||
| Axes | 3-axis inclination measurement with respect to gravity’s direction. Reports the two axes of rotation from the horizontal plane in any orientation | ||
| Resolution | 0,001° / 0.018 mm/m | ||
| Precision (1s) | 0,002° / 0.035 mm/m | ||
| Measurement frequency | 1 to 288 times per day (configurable via the Parvamoti platform) | ||
| 10 | Certificates (pending) |       |
* Based on comparing daily averages of at least 12 daily measurements under similar climatic (temperature) conditions.
